Drive mode |
Driven by AC servo motor |
|
Size |
The base is 160*160mm; the height is 929.3mm |
|
Range of motion |
The maximum moving radius is 911mm |
|
Fuselage weight |
40kg |
|
Bag stacking speed |
The angular velocity is 280°/S; the speed is 40 pieces per minute |
This CCD Visual Valve Adding Robot is a high-precision, high-efficiency intelligent device designed for automated packaging and valve-adding processes. Driven by an AC servo motor, it ensures stable operation and fast response. With a compact structure, the robot has a base size of 160×160mm and a height of only 929.3mm, making it space-efficient and suitable for various production environments. It offers a maximum motion radius of 911mm, enabling flexible operation within its workspace. Integrated with a CCD visual system and high-speed motion control, the robot can process up to 40 bags per minute, achieving an angular velocity of 280°/s, which significantly enhances packaging efficiency. Weighing just 40kg, it is lightweight and easy to integrate into different automated production lines.
